LDC5101

Product Feature:

1.Energy saving, no UV, infrared and mercury pollution, in line with ROHS requirements;

2.The base is made of all-aluminum die-casting process, which is good for heat dissipation when assembling LED lamps and can achieve the purpose of anti-corrosion;

3.Transparent cover with high transmittance PC material, light transmittance of more than 90%;

4.The entire lamp protection level of IP65, silicone waterproof, stainless steel screws with this section of the lamp to achieve the perfect waterproof effect, waterproof, dustproof, anti-corrosion (explosion-proof) structure makes this section lamps suitable for use in a variety of environments;

5.Isolation low-voltage constant current drive, with anti-over-current, over voltage, short circuit protection and other functions; safe, stable and reliable;

6.The use of imported light source and advanced cooling technology, the product MTBF up to 25000hr;

7.Could be frequently switched on and off, no flicker and glare phenomenon; while good color performance; seismic performance;

8.The appearance of simple and generous, fashionable and suitable for a variety of lighting;


Application Area:

Apply to the bathroom, indoor and outdoor channels, water room, canopy, warehouse, balcony and other regional lighting.


Technical parameters
Input Voltage AC100-240V 50/60Hz
Light Source LED
IP IP65
CRI ≥80
CCT 3000K-6500K
Material ABS+PS




Order number Power Luminous(lm) Dimensions(mm)
LDC5101-15W 15W 1650lm φ275*90
LDC5101-20W 20W 2200lm φ330*100
