Product Features:
1、Special cooling structure design, light source cavity, electrical cavity, wiring cavity are set independently, thermal performance and reliable, to ensure reliable light source;
2、Transparent parts with anti-glare anti-glare tempered glass, light transmittance of up to 99%, high tempered, strong resistance;
3、Open the cover power off design, make the installation more convenient and safe. The capping post automatically recloses the power supply. The open cover post automatically disconnects the power supply. It will not cause the internal cable knot or even the twisting when the traditional explosion-proof light is installed Short circuit leakage phenomenon;
4、Using no light loss reflector, high light reflectivity, uniform light.
Applicable Area:
1、Widely used in petroleum, petrochemical, chemical, coal, oil and other flammable and explosive hazardous locations;
2、Zone 1 and Zone 2 for Class IIA, IIB, IIC and explosive gas atmospheres, T1-T6 temperature group.
Technical parameters | |
Input Voltage | AC100-240V 50/60Hz |
Light Source | LED |
Exd | ExdIICT6GB |
IP | IP65 |
WF | WF2 |
CRI | ≥80 |
CCT | 3000K-6500K |
Holder | G3/4 |
Order number
Power
Luminous(lm)
Dimensions(mm)
LBGT4918-30
30W
3000lm
268*268*195
LBGT4918-50
50W
5000lm
268*268*195
LBGT4918-70
70W
7000lm
268*268*195
