Product Features:
1、the shell is made of high strength aluminum alloy die-casting, surface high-pressure electrostatic spray, waterproof and dustproof;
2、Professional optical software design of the secondary light distribution system, the beam distribution is reasonable, uniform illumination, good light efficiency;
3、transparent cover choose PC material, high light transmittance, impact resistance;
4、a street lamp, bracket-type options to meet the requirements of the workin.
Applicable Area:
1、For metallurgical coke plant, power gas plants, oil depots and other flammable and explosive areas of road lighting;
2、For explosive gas atmospheres Zone 1, Zone 2;
3、Suitable for IIA, IIB, IIC explosive atmosphere;
4、Suitable for temperature group T1 ~ T6 environment.
Technical parameters | |
Input Voltage | AC100-240V 50/60Hz |
Light Source | LED |
EXD | ExdIICT6GB |
IP | IP65 |
WF | WF2 |
CRI | ≥80 |
CCT | 3000K-6500K |
Order number | Power | Luminous(lm) | Dimensions(mm) |
LBZD4710-80 | 80W | 7200lm | 403*310*80 |
LBZD4710-120 | 120W | 10800lm | 530*310*80 |
LBZD4710-160 | 160W | 14400lm | 657*310*80 |
LBZD4710-200 | 200W | 18000lm | 784*310*80 |
