Product Feature:
1.The whole lamp uses a solid aluminum alloy, the use of innovative modular fin group to optimize the duct, LED light source close to the radiator,With the whole lamp cooling technology, the perfect and efficient solution to the LED cooling problem, greatly extending the life of the light source;
2.Transparent design of the heat sink module and the lamp shell is more than one, avoiding the accumulation of dust and water, reducing the pressure of cleaning and maintenance;
3.Prospective ultra-thin form factor design, compact structure, simple shape, efficient cooling while greatly reducing the size and weight of the lamp to facilitate storage and transport and maintenance;
4.Silicone ring sealing process, completely prevent the intrusion of dust, protection grade IP65;
5.Independent power supply bit design, not affected by the temperature of the LED lamp body, improve the power efficiency, stability and life expectancy, but also facilitate routine maintenance;
6.Shell paint treatment, the radiator anodized, forming a protective layer on the surface, greatly improving corrosion resistance, suitable for harsh outdoor environment.
Application Area:
Widely used in roads, highways, elevated roads, urban streets, flyovers, pedestrian crossings and other road lighting and plazas, schools, residential areas, industrial areas, parks and other places requiring outdoor lighting.
Technical parameters | |
Input Voltage | AC100-240V 50/60Hz |
Light Source | LED |
IP | IP65 |
CRI | ≥80 |
CCT | 3000K-6500K |
Beam Angel | 140*75° |
Order number | Power | Luminous(lm) | Dimensions(mm) |
LZD7120-60 | 60W | 7200lm | 495*292*98 |
LZD7120-90 | 90W | 10800lm | 587*292*98 |
LZD7120-120 | 120W | 14400lm | 679*292*98 |
LZD7120-150 | 150W | 18000lm | 771*292*98 |
LZD7120-180 | 180W | 21600lm | 863*292*98 |
